StartBox 24 Volt Pump Start Relay

StartBox 24 Volt Pump Start Relay

Introducing the StartBOX Pump Start Relay, your ultimate solution for efficient pump operation! This robust blue box is designed for “pilot duty” operation, making it compatible with all types of electrically driven pump equipment. With a powerful 40 amp relay, it effortlessly supports single-phase pumps ranging from 3/4 hp to 5 hp. Installation is a breeze, and it works seamlessly with controllers that have a .36 amp signal or stronger. Say goodbye to confusion over relay choices—choose the StartBOX for reliable performance and peace of mind!
This unit is used with the Hydroponic Irrigation Controller to run the irrigation pump of your garden system.

$124.98

SKU: MPSR24 Categories: , , ,

This flexible, easy-to-install pump start relay provides “pilot-duty” operation for all electrically driven pump equipment. No
need to wonder which relay to use, the StartBox has a 40 amp relay to work equally well with single phase 3/4 hp to 5 hp.
For use with controllers with a .36 amp signal or stronger.
• Works with any residential turf irrigation pump – available in 24v, 110v, and 220v coils
• Color-coded wiring – Makes hook up a Breeze
• UL and CUL listed relay and enclosure – safe and reliable Construction
• Dimensions – 6″x6″x4″
• UL and CUL listed relay
• NEMA 3R UL listed enclosure – approved for outdoor use, available in stainless steel or powder coated blue or grey

Specifications

  • Signal Voltage: 24V
  • Electrical Rating: 120V-24FLA, 240V-28FLA
  • Largest Motor: 120V-2HP, 240V-5HP
  • Short Circuit Rating: 120V-5KA, 240V-5KA
  • Hertz: 60
  • Inrush/Run: 360MA/
  • UL Listed

This flexible, easy-to-install pump start relay provides "pilot-duty" operation for all electrically driven pump equipment. No
need to wonder which relay to use, the StartBox has a 40 amp relay to work equally well with single phase 3/4 hp to 5 hp.
For use with controllers with a .36 amp signal or stronger.
• Works with any residential turf irrigation pump - available in 24v, 110v, and 220v coils
• Color-coded wiring - Makes hook up a Breeze
• UL and CUL listed relay and enclosure - safe and reliable Construction
• Dimensions - 6"x6"x4"
• UL and CUL listed relay
• NEMA 3R UL listed enclosure - approved for outdoor use, available in stainless steel or powder coated blue or grey

Specifications

  • Signal Voltage: 24V
  • Electrical Rating: 120V-24FLA, 240V-28FLA
  • Largest Motor: 120V-2HP, 240V-5HP
  • Short Circuit Rating: 120V-5KA, 240V-5KA
  • Hertz: 60
  • Inrush/Run: 360MA/
  • UL Listed
